1.25G 80km 1550/1310nm
千兆单纤光模块80km 1550/1310nm

SBP5324-L8xx

1.25G SFP Optical Transceiver, 80km Reach LC

 SBP5324-L8xx

1.25G SFP Optical Transceiver, 80km Reach LC

Features

  •   Dual data-rate of 1.25G operation

  • 1550nm DFB laser and 1310 PIN photo-detector for 80km transmission
  • Compliant with SFP MSA and SFF-8472 with duplex LC receptacle
  • Digital Diagnostic Monitoring: Internal Calibration or External Calibration
  • Compatible with SONET OC-24-LR-1
  • Compatible with RoHS
  • +3.3V single power supply

Applications

l  SDH STM-1, I-1,S-1.1

l  SONET OC-3 IR-1

l  Router/Server interface

l  Other optical transmission systems



The SFP-BIDI transceivers are high performance, cost effective modules supporting dual data-rate of 1.25Gbps and 80km transmission distance with SMF.

The transceiver consists of three sections: a FP laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.

The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472. For further information, please refer to SFP MSA.



Ordering information

Part Number

Product Description

SBP5324-L8NC

1550nm/1310nm,  1.25Gbps,  LC,  80km,  0°C~+70°C,  without DDM

SBP5324-L8NT

1550nm/1310nm, 1.25Gbps,  LC,  80km,  -40°C~+85°C, without DDM

SBP5324-L8DC

1550nm/1310nm, 1.25Gbps,  LC,  80km,  0°C~+70°C,  with DDM

SBP5324-L8DT

1550nm/1310nm,  1.25Gbps,  LC,  80km,  -40°C~+85°C, with DDM
